Magellan 2200VS User Manual

5-138 Magellan
TM
2200VS/2200VS and 2300HS/2300HS
RS-232 TTL
Specifies whether RS-232 interface provides TTL levels on the output
pins TxD and RTS.
Choices are:
• Normal RS-232 levels
• TTL levels
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code below which represents the desired setting for this
feature. You’ll need to cover any unused bar codes on this and the
facing page to ensure that the scanner reads only the bar code you
intend to scan.
3. Complete the programming sequence by scanning the SWITCH
bar code.
RS-232 LEVELS = NORMAL RS-232
RS-232 LEVELS = TTL

Magellan 2200VS Specifications

General

Scan Technology	Laser
Connectivity Technology	Wired
Light Source	Visible Laser Diode (VLD)
Operating Temperature	10° to 40° C (50° to 104° F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% non-condensing
Interface	RS-232, USB
