Magellan 2200VS User Manual

B-382 Magellan
TM
2200VS/2200VS and 2300HS/2300HS
Auxiliary Port
External Handheld Input
Connector Hardware
RJ45, 10 Position
Cable Pinout
Table B-1
PIN # FUNCTION DESCRIPTION
1 DTR Data Terminal Ready
2 CTS in Clear To Send (input)
3 N/C No Connection - Reserved
4 RTS out Request To Send (output)
5 RxD in Receive Data (Input)
6 TxD out Transmit Data (output)
7 ~EAS_GOOD READ Special use Good Read
8 +5V out (500mA max) +5V out
9 GND Signal Ground
10 SPKR OUT Speaker Out

Magellan 2200VS Specifications

General

Scan Technology	Laser
Connectivity Technology	Wired
Light Source	Visible Laser Diode (VLD)
Operating Temperature	10° to 40° C (50° to 104° F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% non-condensing
Interface	RS-232, USB
