Magellan 2200VS User Manual

5-246 Magellan
TM
2200VS/2200VS and 2300HS/2300HS
UPC/EAN Stitch Unlike Label Halves
When enabled, this allows the scanner the ability to stitch two UPC-A /
EAN-13 label halves together that may contain differing characters.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan either the enable or disable bar code below. You’ll need to cover
any unused bar codes on this and the facing page to ensure that the
scanner reads only the bar code you intend to scan.
3. Complete the programming sequence by scanning the SWITCH
bar code.
UPC/EAN STITCH UNLIKE LABEL HALVES = DISABLE
UPC/EAN STITCH UNLIKE LABEL HALVES = ENABLE

Magellan 2200VS Specifications

General

Scan Technology	Laser
Connectivity Technology	Wired
Light Source	Visible Laser Diode (VLD)
Operating Temperature	10° to 40° C (50° to 104° F)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% non-condensing
Interface	RS-232, USB
