Appendix – Control Power Consumption
138
Appendix
Control Power Consumption
Drive Model Number
Control Power (230VAC) consumption (max)*
kVA Watts Current (Amps)
QDC125-xxxx-xx 0.525 525 2.25
QDC150-xxxx-xx 0.525 525 2.25
QDC200-xxxx-xx 0.525 525 2.25
QDC250-xxxx-xx 0.600 600 2.6
QDC300-xxxx-xx 0.600 600 2.6
*Note: Does not include the Elevator Brake
Watts Loss
Drive Model Number
Total System Power Loss (max)**
no Auto Transformer
Total System Power Loss (max)**
with 480VAC:380VAC Auto Transformer
Watts BTU Watts BTU
QDC125-xxxx-xx 2,500 8,600 3,000 10,000
QDC150-xxxx-xx 2,900 9,900 3,400 11,700
QDC200-xxxx-xx 3,700 12,500 4,400 14,900
QDC250-xxxx-xx 4,500 15,500 5,400 18,700
QDC300-xxxx-xx 5,350 18,300 6,400 21,700
**Note: Includes both Control Power and 3-Phase Input Power Consumption
Input / Output Ratings
Drive Model Number
Input Output (rated max)
Voltage (V) Current (A) Voltage (V) Current (A) Power (kW)
QDC125-xxxx-xx 150 – 480 88 50 – 550 125 62.5
QDC150-xxxx-xx 150 – 480 106 50 – 550 150 75
QDC200-xxxx-xx 150 – 480 141 50 – 550 200 100
QDC250-xxxx-xx 150 – 480 176 50 – 550 250 125
QDC300-xxxx-xx 150 – 480 212 50 – 550 300 150
