Line Side Power Converter A5 submenu
NOTE: The only parameter that should ever need to be adjusted is INPUT L-L VOLTS. Other
parameters are for Magnetek Engineering use only.
Parameter Description Units Default Range
Hidden
Item
Run
lock
out
Id REG PROP GAIN
Proportional gain for out-of-
phase current regulator
none 0.30 0.00 – 9.99
N N
Id REG INTEGRAL
GAIN
Integral gain for out-of-phase
current regulator
none 10 0 – 999
N N
Iq REG PROP GAIN
Proportional gain for in-phase
current regulator
none 0.30 0.00 – 9.99
N N
Iq REG INTEGRAL
GAIN
Integral gain for in-phase
current regulator
none 40 0 – 999
N N
DC BUS REG P
GAIN
Proportional gain for bus
voltage regulator
none 3.00 0 – 9.99
N N
DC BUS REG I GAIN
Integral gain for bus voltage
regulator
none 40 0 – 999
N N
INPUT L-L VOLTS
(Input Line to Line Voltage -
Input Voltage)
This parameter sets the nominal
input voltage to the drive. Must
be set correctly to calibrate DC
bus voltage regulation and
precharge.
volts 200 150 – 480
N Y
INITIAL L FREQ
(Initial Line Frequency)
This parameter sets the initial
frequency of the input line
voltage. The defaulted value of
55Hz will work for most
applications, however, when
line power is switched from
utility power to emergency
power, this value should be set
for the actual line power input
frequency.
Hz 55 50 – 60
N Y
DC BUS V BOOST
(DC bus voltage reference)
Adjusts the DC bus voltage
boost above the peak of line
voltage.
Note: The bus must be higher
than the Motor Armature
Voltage and higher than the line
voltage for proper line side
regulation of harmonics and
power factor.
Vdc 30 15 – 75
N N
SW BUS OV LEVEL
(Software Bus Overvoltage
Level) DC bus software
Overvoltage trip point.
Vdc 850 100 – 850
N N
BUS VREF SOURCE
(Bus Voltage Reference
Source) Selects the bus
voltage boost reference.
 Track Line V uses the actual
line voltage for the bus
reference. Recommended
for systems with a stiff line.
 Trk Vin Param uses INPUT
L-L VOLTS (A5) for the bus
reference. Recommended to
systems with a soft line.
none
TRACK
LINE V
 Track Line V
 Trk Vin Param
N N
