Quattro DC Quick Parameter Reference
16
Menu Parameter Unit
U1 Password U1 Submenu
U1 Enter password -
U1 New password -
U1 Password Lockout -
U2 Hidden Items U2 Submenu
U2 Hidden Items Enable -
U3 Units U3 Submenu
U3 Units Selection -
U4 Ovrspeed Test U4 Submenu
U4 Overspeed Test -
U5 Restore Dflts U5 Submenu
U5 Restore Motor Defaults -
U5 Restore Drive Defaults -
U5 Restore Utility Defaults -
U6 Motor Side Info U6 Submenu
U6 MS Type -
U6 MS Platform -
U6 Field Module -
U6 MS Code Version -
U6 MS S/W Date -
U6 MS S/W Time -
U6 MS PIB Module -
U6 MS FPGA Revision -
U6 MS Cube ID -
U7 Line Side Info U7 Submenu
U7 LS Type -
U7 LS Code Version -
U7 LS S/W Date -
U7 LS S/W Time -
U7 LS FPGA Rev -
U7 LS Cube ID -
U8 Hex Monitor1 U8 Submenu
U8 Addr1 -
U8 Addr2&
U8 Addr3&
F1 Active Faults F1 Submenu
F1 Display Active Faults -
F1 Reset Active Faults -
F2 Faults History F2 Submenu
F2 Display Fault History -
F2 Clear Fault History -
F2 Display Fault Counters -
Introduction
Drive Ratings and Specifications
The Quattro drive is designed for connection to
a 4 wire grounded 3-phase input along with a
single-phase 230 VAC control power input.
Basic Drive Specifications
 125, 150, 200, 250, 300 amps DC armature
output (Elevator Run Current) at up to
550VDC in 2 basic model sizes
 150% overload for 60 seconds
 250% overload for 6 seconds
