Component Locations
Figure 31: Component Locations in Front of Drive
3-Phase Input
Power and AC
input Fuses
Motor Field
Controller (A24)
UTM
PCM
Line Side Converter
Optional
Dynamic Braking
Resistors
Control Power Fuses
(F1 & F2) and Field
Supply fuses (F3 & F4)
Control Power
EMI Filter
Motor
Contactor (1M)
Electrical
Control Board
Bus Discharge
Relay
Motor Side Inverter
and Control
Electronics
Cooling Fans
Optional Low Voltage
Field Supply or optional
Field Filter
Optional
Control
Transformer
