Appendix – Component Locations
150
Figure 32: Component Locations with Front End Removed
AC Capacitor
Assembly
Inductor
Bus Discharge
Resistor
Optional Armature
Filter
Line Side Converter
Optional Dynamic
Braking Resistors
Motor Side Inverter
DC Bus Cap Board
Optional Control
Transformer
