Magnetek Elevator Quattro DC - Motor Side Power Convert A4 Submenu

Quattro DC MS Pwr Cnvrt A4 Submenu
55
Motor Side Power Convert A4 submenu
Parameter Description Units Default Range
Hidden
Item
Run
lock
out
ARM
INDUCTANCE
(Armature Circuit Inductance) Affects
tuning of the armature current regulator.
Load this parameter with known or
measured value. Only used if GAIN
SELECTION (A4) is set to Manual.
mH 10.00 0.01 – 327.67
Y N
ARM
RESISTANCE
(Armature Circuit Resistance) Affects
tuning of the armature current regulator.
Load this parameter with known or
measured value. Only used if GAIN
SELECTION (A4) is set to Manual.
ohm 0.1000 0.0001 – 2.9999
Y N
MOTOR FIELD
RES
(Motor Field Resistance) Motor Field
Resistance affects the tuning of the field
current regulator. This parameter is
used only if GAIN SELECTION (A4) is
set to MANUAL.
ohm 9.0 0.0 – 3276.7
Y N
MOTOR FIELD
TC
(Motor Field Time Constant) Motor Field
Time Constant affects the tuning of the
field current regulator. This parameter is
used only if GAIN SELECTION (A4) is
set to MANUAL.
sec 0.607 0.000 – 32.767
Y N
AUTO TUNE
MOTOR
(Auto Tune Motor) Begins the procedure
to calculate motor parameters. See
Auto Tune Procedure on page 122.
none
-
Start Auto
Tune?
N Y
GAIN
SELECTION
(Gain Selection) If set to MANUAL, the
armature current regulator uses the
values in ARM RESISTANCE (A4),
ARM INDUCTANCE (A4), MOTOR
FIELD RES (A4), and MOTOR FIELD
TC (A4).
If set to USE SELF TUNE, the armature
current regulator gains are set using
AUTO MEAS ARM L(D2), AUTO MEAS
IR DROP (D2), AUTO MEAS ARM R
(D2), AUTO FIELD RES (D2), and
AUTO FIELD TC (D2).
If set to USE SAVED PAR, the
armature regulator gains are set using
SAVE MEAS ARM L (A6), SAVE IR
DROP (A6), SAVE MEAS ARM R (A6),
SAVE FIELD RES (A6), and SAVE
FIELD TC (A6)
.
If the D2 submenu contains null
values and USE SELF TUNE is
selected, GAIN SELECTION (A4) will
revert back to MANUAL.
If the SAVE MEAS parameters in the
A6 submenu contain null values and
USE SAVED PAR is selected, GAIN
SELECTION (A4) will revert back to
MANUAL.
none
MANUA
L
 Manual
 Use saved par
Use self tune
N N
