Magnetek Elevator Quattro DC - Dimensions; Weights with Top hat

Appendix – Dimensions and Weights
142
Dimensions / Weights with Top Hat
On drives that require both the Auto Transformer option and the Dynamic Braking Resistor Option, the
Auto Transformer will be placed at the bottom of the cabinet and the Dynamic Braking Resistors will
be placed in a sheet metal box at the top of the drive.
Excluding customer I/O panel
Drive Model
Number
Dimensions
Weight*
Height Width Depth
inches mm inches mm inches mm lbs kg
QDC125-xxxx-xxx
82.9 2140 24 613 19 483 560 255
QDC150-xxxx-xxx
82.9 2140 24 613 19 483 560 255
QDC200-xxxx-xxx
82.9 2140 24 613 19 483 570 260
QDC250-xxxx-xxx
82.9 2140 24 613 19 483 590 268
QDC300-xxxx-xxx
82.9 2140 24 613 19 483 590 268
With Optional Customer I/O panel
Drive Model
Number
Dimensions
Weight*
Height Width Depth
inches mm inches mm inches mm lbs kg
QDC125-xxxx-xxx
82.9 2140 32 813 19 483 720 327
QDC150-xxxx-xxx
82.9 2140 32 813 19 483 720 327
QDC200-xxxx-xxx
82.9 2140 32 813 19 483 740 336
QDC250-xxxx-xxx
82.9 2140 32 813 19 483 760 345
QDC300-xxxx-xxx
82.9 2140 32 813 19 483 760 345
*Includes Auto Transformer weight of ~130lbs
