Appendix – Component Locations
151
Figure 33: Circuit Board Locations
Line Side Main
Control Board (A1)
Line Side Product
Interface Board
(A3)
Line Side Cube I.D.
(A25A3JP10)
Magnetek
Operator
Status LEDs
Motor Side Cube
I.D. (A26A4JP10)
Power Distribution
PCB (A10)
Motor Side Product
Interface Board (A4)
Customer Interface PCB
(A6)
Motor Side Main
Control Board (A2)
