Appendix – Wire Terminal Specs
140
Appendix
Wire Terminal Specs
Customer Interface Board Terminals
English / Imperial Units
Drive Model
Number
Control Wiring Terminals
TB1
Control Wiring Terminals
TB2
Wire Size range
(AWG)
Torque Spec
(in-lb)
Wire Size range
(AWG)
Torque Spec
(in-lb)
QDC125-xxxx-xx #16-#24 1.8-2.2 #14-#24 3.6-4.4
QDC150-xxxx-xx #16-#24 1.8-2.2 #14-#24 3.6-4.4
QDC200-xxxx-xx #16-#24 1.8-2.2 #14-#24 3.6-4.4
QDC250-xxxx-xx #16-#24 1.8-2.2 #14-#24 3.6-4.4
QDC300-xxxx-xx #16-#24 1.8-2.2 #14-#24 3.6-4.4
Metric Units
Drive Model
Number
Control Wiring Terminals
TB1
Control Wiring Terminals
TB2
Wire Size range
(mm
2
)
Torque Spec (N-
m)
Wire Size range
(mm
2
)
Torque Spec (N-
m)
QDC125-xxxx-xx 0.2-1.5 0.2-0.25 0.2-2.5 0.4-0.5
QDC150-xxxx-xx 0.2-1.5 0.2-0.25 0.2-2.5 0.4-0.5
QDC200-xxxx-xx 0.2-1.5 0.2-0.25 0.2-2.5 0.4-0.5
QDC250-xxxx-xx 0.2-1.5 0.2-0.25 0.2-2.5 0.4-0.5
QDC300-xxxx-xx 0.2-1.5 0.2-0.25 0.2-2.5 0.4-0.5
