Quattro DC Parameters
38
Navigation at the Entry Level
When in the entry level, the DATA ENT LED
on the digital operator is lit. At the entry level,
the function of keys are redefined. The
“ESCAPE” key remains as the key used to
move back to the sub-menu level. The left and
right arrow keys are used as cursor positioning
keys and the up and down arrow keys are
used as increment and decrement keys.
Hidden Parameters
There are two types of parameters: standard
and hidden. Standard parameters are
available at all times. Hidden parameters are
for more advanced functions and are available
only if activated. Activation of the hidden
parameters is accomplished by setting of a
utility parameter, HIDDEN ITEMS U2.
RUN/FAULT
SUB MENU
DATA ENT
CONTRACT CAR SPD
A1 0400.0 f
m
