Magnetek Elevator Quattro DC - Page 42

Quattro DC Parameters
40
Configure C0 Utility U0 Faults F0
 User Switches C1
 Spd Command Src
 Run Command Src
 Field Ena Source
 Hi/Lo Gain Src
 Speed Reg Type
 Motor Rotation
 Encoder Connect
 Spd Ref Release
 Cont Confirm Src
 Tach Filter
 PreTorque Source
 PreTorque Latch
 Ptorq Latch Clck
 Fault Reset Src
 Overspd Test Src
 Brake Pick Scr
 Logic Inputs C2
 N.C. Inputs
 Logic Input 1 TB1-1
 Logic Input 2 TB1-2
 Logic Input 3 TB1-3
 Logic Input 4 TB1-4
 Logic Outputs C3
 Logic Output 1 TB1-25
 Logic Output 2 TB1-26
 Logic Output 3 TB1-27
 Logic Output 4 TB1-28
 Logic Output 5 TB1-29
 Logic Output 6 TB1-30
 Analog Outputs C4
 Analog Output 1 TB1-12
 Brake Pick Cnfm
 Brake Hold Src
 Ramped Stop Sel
 Ramp Down En Src
 Brk Pick Flt Ena
 Brk Hold Flt Ena
 Ext Torq Cmd Src
 Dir Confirm
 S-curve Abort
 Priority Message
 Stopping Mode
 Auto Stop
 DSPR Enable
 ARB Select
 Serial Mode
 SER2 FLT mode
 Logic Input 5 TB1-5
 Logic Input 6 TB1-6
 Logic Input 7 TB1-7
 Logic Input 8 TB1-8
 Logic Input 9 TB1-9
 Logic Output 7 TB1-31
 SS Relay 1 TB1-21/22
 SS Relay 2 TB1-23/24
 Relay Coil 1 TB2-1/3/5
 Relay Coil 2 TB2-8/10/12
 Analog Output 2 TB1-13
 Password U1
 Enter Password
 New Password
 Password Lockout
 Hidden Items U2
 Hidden Items Enable
 Units U3
 Units Selection
 Ovrspeed Test U4
 Overspeed Test?
 Restore Dflts U5
 Restore Motor Defaults
 Restore Drive Defaults
 Restore Utility Defaults
 MS Info U6
 MS Type
 MS Platform
 Field Module
 MS Code Version
 MS S/W Date
 MS S/W Time
 MS PIB Module
 MS FPGA Rev
 MS Cube ID
 LS Info U7
 LS Type
 LS Code Version
 LS S/W Date
 LS S/W Time

LS FPGA Rev
 LS Cube ID
 Hex Monitor1 U8
 Addr1
 Addr2&
 Addr3&
 Active Faults F1
 Display Active Faults
 Reset Active Faults
 Fault History F2
 Display Fault History
 Clear Fault History
 Display Fault Counters
