Quattro DC User Switches C1 Submenu
71
Parameter Description Default Choices
Hidden
Item
Run
lock
out
AUTO STOP
(Auto Stop Function Enable)
When the speed command source is set to
multi-step or serial (SPD COMMAND SRC
(C1)=multi-step or serial), the parameter
determines the stopping mode of the drive. The
two selectable methods for the STOPPING
MODE (C1)* parameter are “Immediate” and
“Ramp to stop”.
The Auto Stop function determines how the
drive logic will respond to a zero or non-zero
speed command. The function will only work
when the speed command source is either mult-
step or serial (SPD COMMAND SRC
(C1)=multi-step or serial).
Disabled: When the Auto Stop function is
disabled, the magnitude of the speed command
plays no part in the logical starting or stopping of
the drive.
Enabled: When the Auto Stop function is
enabled and the speed command source is
either multi-step or serial, the following changes
occurs to the start and stop sequence:
Both a Run command and a non-zero
speed command are required to start the
drive
Either the removal of the Run command or
the setting the speed command to zero will
initiate a stop.
Remember, when the auto stop function is
enabled (AUTO STOP (C1)=enabled) both a
non-zero multi-step/serial speed command AND
the run command are required to start the drive.
It makes no difference which signal is enabled
first, the drive does not start until both are
present. When initiating a stop, if STOPPING
MODE (C1) = RAMP TO STOP the drive will
behave the same if either the run or the speed
command is removed. If STOPPING MODE
(C1) = IMMEDIATE, the drive will immediate
drop SPD REF RLS and turn off SPD REG RLS
after BRAKE PICK TIME (A1). With this same
setup, if the speed command is removed before
the run command, the drive will behave the
same as if STOPPING MODE (C1) = Ramp to
Stop.
DISABLE
enable
disable
Y N
