Quattro DC Logic Inputs C2 Submenu
80
step ref b1 Bit 1 of multi-step speed command selection Four inputs, which must be used together as a 4-
bit command for multi-step speed selection. For
more information, see Multistep Ref A3 submenu
on page 53.
step ref b2 Bit 2 of multi-step speed command selection
step ref b3 Bit 3 of multi-step speed command selection
trq ramp
down
(Torque Ramp Down Signal) This function works only if the RAMP STOP SEL (C1) switch is set to
RAMP TO STOP and RAMP DOWN EN SRC (C1) is set to EXTERNAL TB.
up/dwn
(Up/Down Signal) This signal is used to change the sign of the speed command. Default is FALSE;
therefore, positive commands are for the up direction and negative speed command are for the down
direction. Making this input true reverses the car’s direction.
Table 12: Logic Inputs C2 Submenu
