Flex 8EX / 12EX EU System Instruction Manual
March 2018
Page 28 of 66
For 12EX:
NOTE: *PB12 is not available on the A/B transmitters
PB7…PB12  Pushbutton number
Normal  Normal momentary contact
A/1&2…D/3&4  A/B Selector type with designated LED Display (LED 1&2 or LED 3&4)
DIP PB7 PB8 PB9 PB10 PB11 PB12*
10 00101111
A/1&2 Normal Normal Normal Normal Normal
11 00110000
B/1&2 Normal Normal Normal Normal Normal
12 00110001
C/1&2 Normal Normal Normal Normal Normal
13 00110010
D/1&2 Normal Normal Normal Normal Normal
14 00110011 Normal
A/3&4 Normal Normal Normal Normal
15 00110100 Normal
B/3&4 Normal Normal Normal Normal
16 00110101 Normal
C/3&4 Normal Normal Normal Normal
17 00110110 Normal
D/3&4 Normal Normal Normal Normal
18 00110111
A/1&2 A/3&4 Normal Normal Normal Normal
19 00111000
A/1&2 B/3&4 Normal Normal Normal Normal
20 00111001
A/1&2 C/3&4 Normal Normal Normal Normal
21 00111010
A/1&2 D/3&4 Normal Normal Normal Normal
22 00111011
B/1&2 B/3&4 Normal Normal Normal Normal
23 00111100
B/1&2 C/3&4 Normal Normal Normal Normal
24 00111101
B/1&2 D/3&4 Normal Normal Normal Normal
25 00111110
C/1&2 C/3&4 Normal Normal Normal Normal
26 00111111
C/1&2 D/3&4 Normal Normal Normal Normal
27 01000000
D/1&2 D/3&4 Normal Normal Normal Normal
