Flex 8EX / 12EX EU System Instruction Manual
March 2018
Page 29 of 66
NOTE: *PB12 is not available on the A/B transmitters
PB7…PB12  Pushbutton number
Normal  Normal momentary contact
A/1&2…D/3&4  A/B Selector type with designated LED Display (LED 1&2 or LED 3&4)
DIP PB7 PB8 PB9 PB10 PB11 PB12*
28 01000001 Normal Normal
A/1&2 Normal Normal Normal
29 01000010 Normal Normal
B/1&2 Normal Normal Normal
30 01000011 Normal Normal
C/1&2 Normal Normal Normal
31 01000100 Normal Normal
D/1&2 Normal Normal Normal
32 01000101 Normal Normal Normal
A/3&4 Normal Normal
33 01000110 Normal Normal Normal
B/3&4 Normal Normal
34 01000111 Normal Normal Normal
C/3&4 Normal Normal
35 01001000 Normal Normal Normal
D/3&4 Normal Normal
36 01001001 Normal Normal
A/1&2 A/3&4 Normal Normal
37 01001010 Normal Normal
A/1&2 B/3&4 Normal Normal
38 01001011 Normal Normal
A/1&2 C/3&4 Normal Normal
39 01001100 Normal Normal
A/1&2 D/3&4 Normal Normal
40 01001101 Normal Normal
B/1&2 B/3&4 Normal Normal
41 01001110 Normal Normal
B/1&2 C/3&4 Normal Normal
42 01001111 Normal Normal
B/1&2 D/3&4 Normal Normal
43 01010000 Normal Normal
C/1&2 C/3&4 Normal Normal
44 01010001 Normal Normal
C/1&2 D/3&4 Normal Normal
45 01010010 Normal Normal
D/1&2 D/3&4 Normal Normal
