NOTE: *PB12 is not available on the A/B transmitters
PB7…PB12  Pushbutton number
Normal  Normal momentary contact
A/1&2…D/3&4  A/B Selector type with designated LED Display (LED 1&2 or LED 3&4)
DIP PB7 PB8 PB9 PB10 PB11 PB12*
46 01010011 Normal Normal Normal Normal
A/1&2 Normal
47 01010100 Normal Normal Normal Normal
B/1&2 Normal
48 01010101 Normal Normal Normal Normal
C/1&2 Normal
49 01010110 Normal Normal Normal Normal
D/1&2 Normal
50 01010111 Normal Normal Normal Normal Normal
A/3&4
51 01011000 Normal Normal Normal Normal Normal
B/3&4
52 01011001 Normal Normal Normal Normal Normal
C/3&4
53 01011010 Normal Normal Normal Normal Normal
D/3&4
54 01011011 Normal Normal Normal Normal
A/1&2 A/3&4
55 01011100 Normal Normal Normal Normal
A/1&2 B/3&4
56 01011101 Normal Normal Normal Normal
A/1&2 C/3&4
57 01011110 Normal Normal Normal Normal
A/1&2 D/3&4
58 01011111 Normal Normal Normal Normal
B/1&2 B/3&4
59 01100000 Normal Normal Normal Normal
B/1&2 C/3&4
60 01100001 Normal Normal Normal Normal
B/1&2 D/3&4
61 01100010 Normal Normal Normal Normal
C/1&2 C/3&4
62 01100011 Normal Normal Normal Normal
C/1&2 D/3&4
63 01100100 Normal Normal Normal Normal
D/1&2 D/3&4
