Flex 8EX / 12EX EU System Instruction Manual
March 2018
Page 36 of 66
NOTE: *PB12 is not available on the A/B transmitters
PB7…PB12  Pushbutton number
Normal  Normal momentary contact
A/1&2…D/3&4  A/B Selector type with designated LED Display (LED 1&2 or LED 3&4)
DIP PB9 PB10 PB11 PB12*
113 10001111 Normal Normal
A/1&2 Normal
114 10010000 Normal Normal
B/1&2 Normal
115 10010001 Normal Normal
C/1&2 Normal
116 10010010 Normal Normal
D/1&2 Normal
117 01010111 Normal Normal Normal
A/3&4
118 01011000 Normal Normal Normal
B/3&4
119 01011001 Normal Normal Normal
C/3&4
120 01011010 Normal Normal Normal
D/3&4
121 10010011 Normal Normal
A/1&2 A/3&4
122 10010100 Normal Normal
A/1&2 B/3&4
123 10010101 Normal Normal
A/1&2 C/3&4
124 10010110 Normal Normal
A/1&2 D/3&4
125 10010111 Normal Normal
B/1&2 B/3&4
126 10011000 Normal Normal
B/1&2 C/3&4
127 10011001 Normal Normal
B/1&2 D/3&4
128 10011010 Normal Normal
C/1&2 C/3&4
129 10011011 Normal Normal
C/1&2 D/3&4
130 10011100 Normal Normal
D/1&2 D/3&4
