Flex 8EX / 12EX EU System Instruction Manual
March 2018
Page 35 of 66
NOTE: *PB12 is not available on the A/B transmitters
PB7…PB12  Pushbutton number
Normal  Normal momentary contact
A/1&2…D/3&4  A/B Selector type with designated LED Display (LED 1&2 or LED 3&4)
DIP PB9 PB10 PB11 PB12*
95 10000001 Normal
A/1&2 Normal Normal
96 10000010 Normal
B/1&2 Normal Normal
97 10000011 Normal
C/1&2 Normal Normal
98 10000100 Normal
D/1&2 Normal Normal
99 01000101 Normal Normal
A/3&4 Normal
100 01000110 Normal Normal
B/3&4 Normal
101 01000111 Normal Normal
C/3&4 Normal
102 01001000 Normal Normal
D/3&4 Normal
103 10000101 Normal
A/1&2 A/3&4 Normal
104 10000110 Normal
A/1&2 B/3&4 Normal
105 10000111 Normal
A/1&2 C/3&4 Normal
106 10001000 Normal
A/1&2 D/3&4 Normal
107 10001001 Normal
B/1&2 B/3&4 Normal
108 10001010 Normal
B/1&2 C/3&4 Normal
109 10001011 Normal
B/1&2 D/3&4 Normal
110 10001100 Normal
C/1&2 C/3&4 Normal
111 10001101 Normal
C/1&2 D/3&4 Normal
112 10001110 Normal
D/1&2 D/3&4 Normal
