Flex 8EX / 12EX EU System Instruction Manual
March 2018
Page 34 of 66
For 12EX:
NOTE: *PB12 is not available on the A/B transmitters
PB7…PB12  Pushbutton number
Normal  Normal momentary contact
A/1&2…D/3&4  A/B Selector type with designated LED Display (LED 1&2 or LED 3&4)
DIP PB9 PB10 PB11 PB12*
77 01110011
A/1&2 Normal Normal Normal
78 01110100
B/1&2 Normal Normal Normal
79 01110101
C/1&2 Normal Normal Normal
80 01110110
D/1&2 Normal Normal Normal
81 00110011 Normal
A/3&4 Normal Normal
82 00110100 Normal
B/3&4 Normal Normal
83 00110101 Normal
C/3&4 Normal Normal
84 00110110 Normal
D/3&4 Normal Normal
85 01110111
A/1&2 A/3&4 Normal Normal
86 01111000
A/1&2 B/3&4 Normal Normal
87 01111001
A/1&2 C/3&4 Normal Normal
88 01111010
A/1&2 D/3&4 Normal Normal
89 01111011
B/1&2 B/3&4 Normal Normal
90 01111100
B/1&2 C/3&4 Normal Normal
91 01111101
B/1&2 D/3&4 Normal Normal
92 01111110
C/1&2 C/3&4 Normal Normal
93 01111111
C/1&2 D/3&4 Normal Normal
94 10000000
D/1&2 D/3&4 Normal Normal
