Flex 8EX / 12EX EU System Instruction Manual
March 2018
Page 33 of 66
4.1.3.4 Inline Pushbutton Configuration (A/B Selector)
There are four (4) different types of A/B selector sequences available on the Flex
system. Choose the one that is most suitable for your application.
Type-A selector sequence: A+B
 A  B  A+B…
Type-B selector sequence: Off
 A  B  Off  A  B…
Type-C selector sequence: A
 B  A+B  A  B  A+B…
Type-D selector sequence: Off
 A  B  A+B  Off  A  B  A+B…
For 8EX:
NOTE: *PB8 is not available on the A/B transmitters
PB5…PB8  Pushbutton number
Normal  Normal momentary contact
A/1&2…D/3&4  A/B Selector type with designated LED Display (LED 1&2 or LED 3&4)
DIP PB5 PB6 PB7 PB8*
29 01110011 Normal Normal
A/1&2 Normal
30 01110100 Normal Normal
B/1&2 Normal
31 01110101 Normal Normal
C/1&2 Normal
32 01110110 Normal Normal
D/1&2 Normal
33 00110011 Normal Normal Normal
A/3&4
34 00110100 Normal Normal Normal
B/3&4
35 00110101 Normal Normal Normal
C/3&4
36 00110110 Normal Normal Normal
D/3&4
37 01110111 Normal Normal
A/1&2 A/3&4
38 01111000 Normal Normal
A/1&2 B/3&4
39 01111001 Normal Normal
A/1&2 C/3&4
40 01111010 Normal Normal
A/1&2 D/3&4
41 01111011 Normal Normal
B/1&2 B/3&4
42 01111100 Normal Normal
B/1&2 C/3&4
43 01111101 Normal Normal
B/1&2 D/3&4
44 01111110 Normal Normal
C/1&2 C/3&4
45 01111111 Normal Normal
C/1&2 D/3&4
46 10000000 Normal Normal
D/1&2 D/3&4
