0000100 Forward and Fast output relays engaged at 2nd speed 4
0000101
Forward, Slow, and Fast output relays engaged at 2nd
speed
4
0000110 ON (right button) & OFF (left button) 2
0001000
ON & OFF - affected by the E-Stop command. When
E-Stop command is initiated, the OFF relay is activated.
2
0001001
ON + START / OFF + START - Prior to pressing the
button you must first rotate and hold the power key switch
at the START position to activate ON or OFF relays.
2
0001010 FWD/REV toggled (latched) 2
0001011
FWD/REV toggled (latched) and affected by the E-Stop
command
2
0100001 Closed/Closed + Brake 4
0100010 Closed/Closed Relay Action + Brake 3
0100011 Opened/Closed Relay Action + Brake 4
Manufacture preset
Dip
Settings
Function Descriptions
# of Relays
Used
