IMPULSE•T Instruction Manual – October 2015
5-3
Application
The application parameters control the acceleration and deceleration characteristics, as well as any
preset frequencies the system will require for operation. Application parameters included in this
section are listed below:
• B1 Preset References
• B2 Reference Limits
• B3 Sequence/Reference Source
• B5 Acceleration/Deceleration
Preset Reference
Table 5-1:Preset Reference Parameter Settings
Table 5-2:Multi-Input Speed Reference Selection
Parameter
Code
Name Function Range
Initial
Value
Access
Level
B1-01 Frequency Reference 1 Sets the frequency of
Minimum Speed/Speed 1.
0.00–E1-04 Hz 6.00 Adv
B1-02 Frequency Reference 2 Sets the Speed 2
frequency.
0.00–E1-04 Hz 30.00 Adv
B1-03 Frequency Reference 3 Sets the Speed 3
frequency.
0.00–E1-04 Hz 60.00 Adv
B1-04 Frequency Reference 4 Sets the Speed 4
frequency.
0.00–E1-04 Hz 0.00 Adv
B1-05 Frequency Reference 5 Sets the Speed 5
frequency.
0.00–E1-04 Hz 0.00 Adv
B1-06 Frequency Reference 6 Sets the Speed 6
frequency.
0.00–E1-04 Hz 0.00 Adv
B1-07 Frequency Reference 7 Sets the Speed 7
frequency.
0.00–E1-04 Hz 0.00 Adv
B1-08 Frequency Reference 8 Sets the Speed 8
frequency.
0.00–E1-04 Hz 0.00 Adv
Speed
Reference
Forward/Reverse
Terminal 1 or 2
H1-01–06 = 80 or 81
Multi-Step Speed 2
H1-01–06 = 0
Multi-Step Speed 3
H1-01–06 = 1
Multi-Step Speed 4
H1-01–06 = 2
STOP
OFF------
B1-01
Speed Ref 1
ON OFF OFF OFF
B1-02
Speed Ref 2
ON ON OFF OFF
B1-03
Speed Ref 3
ON ON ON OFF
B1-04
Speed Ref 4
ON ON ON ON
B1-05
Speed Ref 5
ON ON OFF ON
B1-06
Speed Ref 6
ON OFF ON OFF
B1-07
Speed Ref 7
ON OFF ON ON
B1-08
Speed Ref 8
ON OFF OFF ON
To Next Page
