IMPULSE•T Instruction Manual – October 2015
5-16
Analog Output
The IMPULSE•T has one analog output for the external monitoring of drive conditions.
Table 5-20:Analog Output Parameter Settings
Parameter
Code
Name Function Range
Initial
Value
Access
Level
H4-01 Terminal AM Select Analog output selection for
Terminal AM.
101–113 103 Adv
101 Frequency
Reference
102 Output Frequency
103 Output Current
106 Output Voltage
107 DC Bus Voltage
113 A1 Terminal Input
Level
H4-02 Terminal AM Gain Gain multiplier for Terminal
AM analog output signal
-999.9–999.9% 100.0 Adv
H4-03 Terminal AM Bias Bias multiplier for Terminal
AM analog output signal
-999.9–999.9% 0.0 Adv
