IMPULSE•T Instruction Manual – October 2015
5-12
Table 5-13: Sample Voltage/Frequency Pattern Options for 230 V Class
Table 5-14: Sample Voltage/Frequency Pattern Options for 460 V Class
Motor Set-up
E2-01 sets the full load current (FLA) for the motor. Initial value is determined by O2-04 (kVA
selection).
Table 5-15:Motor Set-up Parameter Settings
E1-04 E1-05 E1-06 E1-07 E1-08 E1-09 E1-10
Hz V Hz Hz V Hz V
1
(3)
60.0 230.0 60.0 3.0 15.0 1.3 8.1
2 60.0 230.0 60.0 3.0 16.1 1.3 9.2
3 60.0 230.0 60.0 3.0 17.3 1.3 10.4
4 60.0 230.0 60.0 3.0 18.4 1.3 11.5
5 60.0 230.0 60.0 3.0 19.6 1.3 12.7
6 60.0 230.0 60.0 3.0 20.7 1.3 13.8
7 60.0 230.0 60.0 3.0 21.9 1.3 15.0
8 60.0 230.0 60.0 3.0 23.0 1.3 16.1
9 60.0 230.0 60.0 3.0 24.2 1.3 17.3
10 72.0 230.0 60.0 3.0 16.1 1.3 9.2
11 72.0 230.0 60.0 3.0 17.8 1.3 10.9
12 72.0 230.0 60.0 3.0 19.6 1.3 12.7
13 90.0 230.0 60.0 3.0 16.1 1.3 9.2
14 90.0 230.0 60.0 3.0 17.8 1.3 10.9
15 90.0 230.0 60.0 3.0 19.6 1.3 12.7
E1-04 E1-05 E1-06 E1-07 E1-08 E1-09 E1-10
Hz V Hz Hz V Hz V
1
(3)
60.0 460.0 60.0 3.0 30.0 1.3 16.2
2 60.0 460.0 60.0 3.0 32.2 1.3 18.4
3 60.0 460.0 60.0 3.0 34.5 1.3 20.7
4 60.0 460.0 60.0 3.0 36.8 1.3 23.0
5 60.0 460.0 60.0 3.0 39.1 1.3 25.3
6 60.0 460.0 60.0 3.0 41.4 1.3 27.6
7 60.0 460.0 60.0 3.0 43.7 1.3 29.9
8 60.0 460.0 60.0 3.0 46.0 1.3 32.2
9 60.0 460.0 60.0 3.0 48.3 1.3 34.5
10 72.0 460.0 60.0 3.0 32.2 1.3 18.4
11 72.0 460.0 60.0 3.0 35.6 1.3 21.8
12 72.0 460.0 60.0 3.0 39.1 1.3 25.3
13 90.0 460.0 60.0 3.0 32.2 1.3 18.4
14 90.0 460.0 60.0 3.0 35.6 1.3 21.8
15 90.0 460.0 60.0 3.0 39.1 1.3 25.3
(3)
Default
Parameter
Code
Name Function Range
Initial
Value
Access
Level
E2-01 Motor Rated FLA Motor-rated current full load
amps
0.12–19.2 A * Adv
* Initial value is determined by O2-04 (kVA Selection)
