IMPULSE•T Instruction Manual – October 2015
5-11
Table 5-11: Inverter Voltage
Table 5-12: V/f Parameters
Inverter
Voltage
E1-01 Setting
Overvoltage Trip Braking Transistor
Trip Reset On Off
230 150-255 400V 380V 380V 375V
460 400 800V 760V 760V 750V
460 <400 720V 680V 660V 650V
Parameter
Code
Name Function Range
Initial
Value
Access
Level
E1-04 Max Frequency Maximum Frequency 40.0–E1-04
Hz
60 Adv
E1-05 Max Voltage Maximum Voltage 230: 0–255 V
460: 0–510 V
230
460
(2)
Adv
E1-06 Base Frequency Motor Base Frequency 0.0–E1-04 Hz 60 Adv
E1-07 Mid Frequency A Midpoint Output
Frequency A
0.0–E1-04 Hz 3.0 Adv
E1-08 Mid Voltage A Midpoint Frequency
Voltage A
230: 0–255 V
460: 0–510 V
15.0
30.0
(2)
Adv
E1-09 Min Frequency Minimum Frequency 0.0–E1-04 Hz 1.3 Adv
E1-10 Min Voltage Minimum Voltage 230: 0–255 V
460: 0–510 V
8.1
16.2
(2)
Adv
(2)
Initial value determined by drive capability
