IMPULSE•T Instruction Manual – October 2015
A-3
IMPULSE•T Parameter Listing
Parameter Parameter Name Default Range Units
Reference
Page
A1-01 Parameter Access Level
0000: Operator Only
0002: Advanced
0000 0000, 0002 -- 4-10
A1-03 Select Motion
00: Traverse
00 00 -- 4-10
A1-04 Speed Reference
00: 2 Speed Multi-Step
01: 3 Speed Multi-Step
02: 5 Speed Multi-Step
03: 2 Step Infinitely Variable
04: Analog - Uni-Polar
01 00–05 -- 4-11
A1-05 Initialize
0000: No Initialize
2220: Initialize drive to factory default
settings
0000 0000, 2220 -- 4-11
B1-01 Frequency Reference 1 6.00 0.00–E1-04 Hz 5-3
B1-02 Frequency Reference 2 30.00 0.00–E1-04 Hz 5-3
B1-03 Frequency Reference 3 60.00 0.00–E1-04 Hz 5-3
B1-04 Frequency Reference 4 0.00 0.00–E1-04 Hz 5-3
B1-05 Frequency Reference 5 0.00 0.00–E1-04 Hz 5-3
B1-06 Frequency Reference 6 0.00 0.00–E1-04 Hz 5-3
B1-07 Frequency Reference 7 0.00 0.00–E1-04 Hz 5-3
B1-08 Frequency Reference 8 0.00 0.00–E1-04 Hz 5-3
B2-01 Frequency Reference Upper Limit 100.0 0.0–110.0 % 5-4
B2-02 Frequency Reference Lower Limit 0.0 0.0–110.0 % 5-4
B3-01 Reference Source
00: Digital Operator
01: Terminals
00 00, 01 -- 5-5
B3-02 Run Source
00: Digital Operator
01: Terminals
01 00, 01 -- 5-5
B3-03 Stop Method
00: Decel to Stop
00 00 -- 5-5
B3-04 Reverse Oper
00: Normal Rotation
01: Exchange Phases
00 00, 01 -- 5-7
B5-01 Accel Time 5.0 0.0–25.5 sec 5-7
B5-02 Decel Time 5.0 0.0–25.5 sec 5-7
D1-02 DC Injection Current 50 0–75 % 5-8
D1-03 DC Injection Time @ Start 0.00 0.00–10.00 sec 5-8
D1-04 DC Injection Time @ Stop 0.50 0.00–10.00 sec 5-8
D9-01 S-Curve Accel @ Start 1.50 0.00–10.00 sec 5-9
D9-02 S-Curve Accel @ End 1.50 0.00–10.00 sec 5-9
D9-03 S-Curve Decel @ Start 1.50 0.00–10.00 sec 5-9
D9-04 S-Curve Decel @ End 0.20 0.00–10.00 sec 5-9
E1-01 Input Voltage 230
460
230: 155–255
460: 310–510
V5-10
* Initial value is determined by O2-04 (kVA selection).
