Digital Output
The IMPULSE•T has one multi-function control output (one relay) for indicating various conditions.
The following table lists the function selections for the multi-function contact outputs.
Table 5-18:Digital Output Parameter Settings
Analog Input
The IMPULSE•T has one analog input for the external input of references and limits.
Table 5-19:Analog Input Parameter Settings
Parameter
Code
Name Function Range
Initial
Value
Access
Level
H2-01 Output Contactor (MC-
MB-MA) Select
Digital Output Function 000–010 000 Adv
000 Brake Release Closed when the drive
provides a voltage or
frequency is output
006 Drive Ready Closed when a drive is ready
and not in a fault state
00EFault Closed during a major fault.
00FNot Used No function
010 Minor Fault Closed during minor fault or
alarm
Parameter
Code
Name Function Range
Initial
Value
Access
Level
H3-01 Terminal A1 Signal Level
Selection
Voltage Selection Analog
Terminal A1
00–03 00 Adv
00 0 to 10 VDC (lower
limit)
01 0 to 10 VDC (no lower
limit)
02 4 to 20 mA
03 0 to 20 mA
H3-03 Terminal A1 Gain Gain multiplier for Terminal A1
analog input signal
-999.9 –
999.9%
100.0 Adv
H3-04 Terminal A1 Bias Bias multiplier for Terminal A1
analog input signal
-999.9 –
999.9%
0.0 Adv
H3-13 Analog Input Filter Time
Constant
Analog input filter average time
for Terminal A1
0.00–2.00
sec
0.03 Adv
