IMPULSE•T Instruction Manual – October 2015
5-5
Sequence/Reference Source
B3-01 and B3-02 determine the source from where the frequency reference and RUN command are
generated.
Table 5-4:Sequence/Reference Source Parameter Settings
Stopping Method
B3-03 selects the stopping method suitable for the particular application.
Table 5-5:Stopping Method Parameter Settings
Parameter
Code
Name Function Range
Initial
Value
Access
Level
B3-01 Reference Source Source from where the frequency
reference is generated.
00, 01 00 Adv
00 Digital Operator Digital Operator (Keypad)*
01 Terminals Analog input terminals
B3-02 Run Source Source from where the RUN
command is generated.
00, 01 01 Adv
00 Digital Operator Digital Operator (Keypad).
01 Terminals Control circuit terminal.
* LO/RE will light up when Run Source is assigned to the operator.
Parameter
Code
Name Function Range
Initial
Value
Access
Level
B3-03 Stop Method Determines stop method. 00 00 Adv
00 Decel to Stop Used to stop when motion is
traverse
(Fig 5-2 & 5-3)
WARNING
Because of the additional potential hazards that are introduced when any drive is operated
locally, we advise you to avoid operating it this way. If you do operate the drive locally, be
aware that the crane or hoist will move when you press the RUN button. If you have questions,
contact Magnetek.
