IMPULSE•T Instruction Manual – October 2015
5-13
Terminal Parameters
There are both digital and analog inputs and outputs that can be programmed for customized
operation and sequencing. These include input and output terminal selection along with serial
communication. Listed below are the parameters in this section that are customizable for your
system.
• H1 Digital Inputs
• H2 Digital Output
• H3 Analog Input
• H4 Analog Output
Digital Inputs
The IMPULSE•T has five multi-function contact inputs for the set-up of numerous functions. The
following table lists the function selections for the multi-function contact inputs (terminals S1 to S5)
and indicates the control modes during which each function can be enabled. An OPE03 error will
occur if a function is programmed in more than one terminal at the same time.
Table 5-16:Digital Inputs Parameter Settings
Parameter
Code
Name Function
Reference
Page
Number
Range
Initial
Value
Access
Level
H1-01 Terminal S1 Select Selects the multi-function
inputs. Setting for S1.
-- 00–81 80 Adv
H1-02 Terminal S2 Select Setting for S2. -- 00–81 81 Adv
H1-03 Terminal S3 Select Setting for S3. -- 00–81 00 Adv
H1-04 Terminal S4 Select Setting for S4. -- 00–81 01 Adv
H1-05 Terminal S5 Select Setting for S5. -- 00–81 0F Adv
00 Multi-Step Ref 2 Multi-Step Speed 2. (B1-02) 5-3
01 Multi-Step Ref 3 Multi-Step Speed 3. (B1-03) 5-3
02 Multi-Step Ref 4 Multi-Step Speed 4. (B1-04) 5-3
05 Accel Command Acceleration function (2nd
step of Two-Step Infinitely
Variable or 3rd step of
Three-Step Infinitely
Variable).
5-3
0F Not used No function - terminal is
disabled
--
20 thru 2FExternal Fault Desired setting is possible.
Input mode: N.O./N.C.,
Detection mode: Always/
During Run (See external
fault response selection
Table 5-17)
5-14
32 Ext BB N.O. N.O.: Baseblock by ON.
Immediate stop at STOP
command; normally open
--
33 Ext BB N.C. N.C.: Baseblock by OFF.
Immediate stop at STOP
command; normally closed
--
3F Fault Reset Reset by ON --
80 Forward Run Forward Run Command
(B1-01)
5-3
81 Reverse Run Reverse Run Command
(B1-01)
5-3
To Next Page
