IMPULSE•T Instruction Manual – October 2015
A-4
E1-04 Max Frequency 60 40.00–E1-04 Hz 5-11
E1-05 Max Voltage 230
460
230: 0.0–255.0
460: 0.0–510.0
V5-11
E1-06 Base Frequency 60 0.00–E1-04 Hz 5-11
E1-07 Mid Frequency A 3.0 0.00–E1-04 Hz 5-11
E1-08 Mid Voltage A 15.0
30.0
230: 0.0–255.0
460: 0.0–510.0
V5-11
E1-09 Min Frequency 1.3 0.00–E1-04 Hz 5-11
E1-10 Min Voltage 8.1
16.2
230: 0.0–255.0
460: 0.0–510.0
V5-11
E2-01 Motor Rated FLA * 0.12–19.2 A 5-12
H1-01 Terminal S1 Select
(See reference page for further
details)
00: Multi-Step Reference 2
01: Multi-Step Reference 3
02: Multi-Step Reference 4
05: Accel Command
0F: Not Used
20~2F: External Fault
32: Ext BB N.O.
33: Ext BB N.C.
3F: Fault Reset
80: Forward Run
81: Reverse Run
80 00–81 -- 5-13
H1-02 Terminal S2 Select
(See page 5-13 for further details)
81 00–81 -- 5-13
H1-03 Terminal S3 Select
(See page 5-13 for further details)
00 00–81 -- 5-13
H1-04 Terminal S4 Select
(See page 5-13 for further details)
01 00–81 -- 5-13
H1-05 Terminal S5 Select
(See page 5-13 for further details)
0F 00–81 -- 5-13
H2-01 Output Contactor (MC-MB-MA) Select
000: Brake Release
006: Inverter Ready
00E: Fault
00F: Not used
010: Minor Fault
000 000–010 -- 5-15
H3-01 Terminal A1 Signal Selection
00: 0 to 10 VDC (lower limit)
01: 0 to 10 VDC (no lower limit)
02: 4 to 20mA
03: 0 to 20mA
00 00–03 -- 5-15
H3-03 Terminal A1 Gain 100.0 -999.9–999.9 % 5-15
H3-04 Terminal A1 Bias 0.0 -999.9–999.9 % 5-15
H3-13 Analog Input Filter Time Constant 0.03 0.00–2.00 sec 5-15
H4-01 Terminal AM Select
101: Frequency Reference
102: Output Frequency
103: Output Current
106: Output Voltage
107: DC Bus Voltage
113: A1 Terminal Input Level
103 101–113 -- 5-16
H4-02 Terminal AM Gain 100.0 -999.9–999.9 % 5-16
Parameter Parameter Name Default Range Units
Reference
Page
* Initial value is determined by O2-04 (kVA selection).
