IMPULSE•T Instruction Manual – October 2015
A-5
H4-03 Terminal AM Bias 0.0 -999.9–999.9 % 5-16
L1-01 Motor Overload Fault Select
00: Disable
01: Standard Fan Cooled
02: Standard Blower Cooler
02 00–02 -- 5-17
L1-02 Motor Overload Time Const 1.0 0.1–5.0 min 5-18
L1-13 Overhead Operation Selection
00: Disable
01: Enable
01 00, 01 -- 5-18
L3-01 Stall Prevention Accel Select
00: Disabled
01: General Purpose
01 00, 01 -- 5-19
L3-02 Stall Prevention Accel Level 120 0–150 -- 5-19
L8-05 Input Phase Loss Selection
00: Disabled
01: Enabled
01 00, 01 -- 5-21
L8-10 Fan Operation Selection
00: Fan On - Run
01: Fan Always On
00 00, 01 -- 5-21
L8-12 Ambient Temp 50 -10–50 °C 5-21
L8-18 Soft CLA Sel
00: Disabled
01: Enabled
01 00, 01 -- 5-21
L9-02 Auto Reset Attempts 03 00–10 -- 5-21
O2-04 kVA Selection
60: Not Used
61: 2001-T
62: 2004-T
63: 2006-T
64: Not Used
65: 2010-T
66: 2012-T
67: Not Used
68: Not Used
91: 4001-T
92: 4002-T
93: 4004-T
94: 4005-T
95: Not Used
96: 4009-T
97: Not Used
-- 60–97 -- 5-22
U1-01 Frequency Reference -- -- Hz 5-23
U1-02 Output Frequency -- -- Hz 5-23
U1-03 Output Current -- -- A 5-23
U1-06 Output Voltage -- -- VAC 5-23
U1-07 DC Bus Voltage -- -- VDC 5-23
U1-10 Input Terminal Status -- -- -- 5-23
U1-11 Output Terminal Status -- -- -- 5-23
U1-13 Terminal A1 Level -- -- % 5-23
U1-14 Flash ID -- -- -- 5-23
U1-19 Memobus Communication Error -- -- -- 5-24
U1-28 Software CPU -- -- -- 5-24
U2-01 Current Fault -- -- -- 5-24
Parameter Parameter Name Default Range Units
Reference
Page
* Initial value is determined by O2-04 (kVA selection).
