16 Series, Model - 2816 4WD
WHEEL MOUNTING TORQUES
Front Wheel Disc to Axle Hub Bolts
...............................118 to 132 Nm (87 to 98 Ib ft)
Rear Wheel Disc to Axle Hub Bolts
...............................118 to 132 Nm (87 to 98 lb ft)
Rear Wheel Rim to Wheel Disc Nuts
........................... 152 to 172 Nm (112 to 127 Ib ft)
IMPORTANT: Check the wheel bolts and nuts after the first 10 hours of
operation and again after every 100 hours of operation. Also do this
procedure any time the wheel or rim is removed.
80
TIRES/WHEELS/SPACING/BALLAST _______________________________________
