29
5. Set the aditional stands “A” Fig. 44 at
the chassis sides with the correspon-
ding safety lock “B”. Open the adjus-
ters “C”, (unscrew) until free the ton-
gue in the tractor hinch.
6. Increase the brake circuit pressure, in
30 - 40 kg/cm² to ensure that the ma-
chine will not move (do not exceed the
200 kg/cm² - 3000 psi)
7. Open the ow shear “A” Fig. 45 un-
der the auger to drain water in case of
rain.
8. Remove the hitch bolt and withdraw
the tractor.
A
When withdrawing the tractor, have the
precaution of not taking off the brake
circuit pressure, not open the height
cylinder block valve.
FIG.44
FIG.45
