BAG END AND CLOUSURE
1. When the end mark of the bag reach the tunnel end, stop loading cereal with the self unload wagon.
2. Empty the bagger grain hopper and the auger.
3. Stop the tractor PTO.
4. Lower the work height H : 10-12 cm (4 - 5 in) Fig. 41 (from rack tho the ground).
5. Fully decrease the brake pressure to 0 kg/cm² (0 psi) and move on with the whole machine tractor, until
detach it from the bag.
6. Close the bag. (See bag clousure)
FILLING PROCESS STOP
If it is stopped the lling process and is
required to move out the tractor, proceed:
1. Empty the bagger grain bin and the au-
ger.
2. Stop the tractor engine and uncouple
the PTO shaft.
3. Verify the hydraulic cylinder valve “A”
Fig. 43 is in “close” position.
4. Remove the pressure from the hydrau-
lic circuit and uncouple the hoses from
the tractor.
FIG.43
