15
4. Raise jack until free the front tire and
withdraw it. The hub “A” Fig. 10 must
be rotated in this position half a turn,
upwards the chassis.
5. Retire bolt “B” Fig. 11, take the tongue
“A” from the handles “C”, take it down
and put the bolts with lock in work po-
sition.
6. Lower jack, until tongue in tractor hit-
ch, at this moment the back wheel will
be free (the machine will be supported
on the two aditionals stands and trac-
tor hitch).
7. Withdraw the jack “A” Fig. 12 and lo-
cate in the transport tongue, with the
position toward inside the tunnel.
If the back wheel is not free, maybe the
adjusters “B” Fig. 9 are not in the more
open position (Inside ear).
FIG.10
FIG.11
FIG.12
Carry out this descending task with at
least two people.
