SPARE PARTS LISTING OF THE ILLUSTRATION Nº 3
POS. DENOMINATION SPARE Nº POS. DENOMINATION SPARE Nº
1 Helical protector 43963-634
2 Elbow 45º - male-male JIC 37º 22524-102
3 Hydraulic cylinder - w/pin and clip 30664-840
4 Hydraulic ferrule for tube 3/8” 28300-100
5 Hydraulic nut Rap Stank 3/8” 27700-107
6 Adapter Rap Stank 3/8” 21101-116
7 Valve double retention “Caproni” 37213-870
8 Adapter male 1/2” - BSPT male 3/8” 21105-113
9 Hydraulic for tube 43963-627
10 Adapter Rap-Semi Stank 1/2” 21101-117
11 Cotter pin Ø 3 x 40 mm 25102-170
12 Brake disk 43925-602
13 Straight grease nipple 30 x 1/16” 24901-100
14 Taper roller bearing Nº 30206 65230-206
15 Washer 43400-613
16 Tube 6.00 x 16” 30643-190
17 Tire 7.00 x 15 – 8 ply 34500-190
18 Rim 6,5 x 15 36012-865
19 Polyethylene cup – black 36615-650
20 Castle hex nut RM 22 x 1,5 mm 27940-106
21 Wheel nut 36621-104
22 Wheel hub 43925-600
23 Taper roller bearing Nº 30209 65230-209
24 Oil seal 44025-612
25 Dust cover washer 44025-611
26 Wheel bolt 30307-115
27 Work axle shaft 43925-205
28 Self lock hex nut RM 16 mm 27963-110
29 Hex bolt RM 16 x 80 mm 21705-488
30 Wheel axle 43925-212
31 Plastic precinct 32102-250
32 Hose Ø ¼” x 4160 mm 43963-122
33 Male-male adapter ½” UNF JIC 37º - ½” BSPT 21110-104
34 Male fast coupler ½” NPT 20204-102
35 Female plastic plug 20212-102
36 Seal kit for hydraulic cylinder 30664-485
