SPARE PARTS LISTING OF THE ILLUSTRATION Nº 6
POS. DENOMINATION SPARE Nº POS. DENOMINATION SPARE Nº
1 Rack hinge pin 43900-635
2 Cotter pin Ø 4 x 30 mm 25102-188
3 Rack support chain 43900-235
4 Chain protection hose 43900-640
5 Hook protection hose 43900-642
6 Tensor adjuster Ø 12 mm 26400-205
7 Fetter 23910-102
8 Bag support rack 43900-294
9 Self lock hex nut RM 12 27963-108
10 LH upper arm basket support 43900-231
11 Bag rise hanger lock 43900-646
12 Hex bolt RM 12 x 65 mm 21705-414
13 RH upper arm basket support 43900-230
14 Bag rise hanger cable 43900-643
15 Self lock hex nut RM 16 mm 27963-110
16 Guide sheave 43300-614
17 Hex bolt RM 16 x 80 mm 21705-488
18 Bag rise hanger 43900-295
19 Clip pin 3,5 x 65 mm 22300-102
20 Black polyethylene cap Ø 7/8” 36026-100
21 Lower arm basket support 43900-296
22 Bag retention rope 43900-641
23 Elastic rope 43900-297
24 Protector 43900-639
25 RH SN bolt RW ¼” x 5/8” 21410-121
26 Spindle 41147-211
27 Hex bolt ½” x 4 ½” 21402-241
28 Winch box 41147-210
29 Spacer 41147-614
30 Handle 41147-212
31 Hex bolt 3/8” x 1 ¼” 21402-183
32 Self lock hex nut RM 10 mm 27963-107
33 Drive sprocket 41147-610
34 Lock bushing 41147-611
35 Lock 41147-612
36 Plain washer Ø 3/8” 20800-104
37 Hex nut 3/8” 27902-105
38 Pressure washer Ø 3/8” 20810-108
39 Spring 36017-902
40 Hex bolt RM 10 x 30 mm 21705-374
41 Rolled pin Ø 5 x 24 mm 23702-283
42 Lock hex nut ½” 27953-104
43 Hex nut ¼” 27902-103
44 Flange 41147-613
45 Plain washer galv. Ø 1/2” 20801-106
