SPARE PARTS LISTING OF THE ILLUSTRATION Nº 7
POS. DENOMINATION SPARE Nº POS. DENOMINATION SPARE Nº
1 RH brake caliper 43963-616
2 Male-male adapter 1/2” UNF JIC 37º - RM 10 x 1 mm 21147-104
3 Elbow 45º male - UNF - JIC 37º female - turning nut 22555-104
4 Hydraulic hose Ø ¼” x 2075 mm 43963-123
5 Helical protector 43963-612
6 Male Tee ½” - ½” - ½” UNF JIC 37º 26519-102
7 Helical protector 43963-613
8 Hydraulic hose Ø ¼” x 1055 mm 43963-124
9 LH brake caliper 43963-615
10 Brake pad 35459-101
11 Pressure washer Ø 12 mm 20814-110
12 Hex bolt RM 12 x 1,5 x 45 mm 21713-410
13 Pump “HYDROM” manual 250/500 kg/cm² 30342-150
14 Self lock hex nut RM 8 x 1,25 mm 27963-106
15 Plain washer Ø 5/16” 20801-103
16 Hex bolt RM 8 x 1.25 x 25 mm 21705-341
17 Elbow 90° male-male 1/4” X 3/8” BSPT 22502-202
18 Valve Mod. VCA- A - B 3/8” BSP 37213-920
19 Tee male-female for circuit hydraulic 301-6-6-6 26521-102
20 Elbow 45º male - female 22552-103
21 Glycerin gauge 34205-121
22 Male-male adapter 21110-103
23 Helical protector 41563-614
24 Hydraulic hose Ø ¼” x 455 mm 43963-125
25 Seal kit for caliper of brake 35458-105
