SPARE PARTS LISTING OF THE ILLUSTRATION Nº 8
POS. DENOMINATION SPARE Nº POS. DENOMINATION SPARE Nº
1 Stand 23804-203
2 Transport tongue pin 43940-213
3 Clip pin 3,5 x 65 mm 22300-102
4 Axle pin 43925-204
5 Dust cover washer 44025-611
6 Taper roller bearing Nº 30209 65230-209
7 Grease nipple 45º - 1/8” 24903-101
8 Hub 46061-603
9 Taper roller bearing Nº 30206 65230-206
10 Black polyethylene cap 36615-650
11 Castle hex nut 22 x 1.5 mm 27940-106
12 Washer 43400-613
13 Wheel bolt 30307-106
14 Oil seal 44025-612
15 Cotter pin DIN 94 Ø 3 x 40 mm 25102-170
16 Axle 43925-200
17 Transport tongue double 43940-216
Transport tongue simple 43940-211
18 Short neck bearing gear 16 T. 23804-102
19 Long neck bearing gear 16 T. 23804-101
Axle point complete mount 43925-011
