–115–
EC40 SELF-CONTAINED AIR-COOLED — STANDARD CUBE (Continued)
24 Hour Ice Production
Continued on next page …
Air Temp. Entering
Condenser °C
Water Temperature °C
10 15 20 25 30 35 40
10 41
15 39 37
20 36 34 33 31 27
25 33 31 30 28 26
30 30 28 26 25 23 22 20
35 23 22 20 18 17
40 17 15 14
45 14 12 11
Based on average ice weight of 0.72 - 0.80 kg per cycle. Individual cube weight 19 grams ±1.
Number of individual cubes per cycle: 40
