–116–
EC40 SELF-CONTAINED AIR-COOLED — STANDARD CUBE (Continued)
Operating Pressures
Air Temp. Entering
Condenser °C
Freeze Cycle Harvest Cycle
Discharge Pressure Suction Pressure Discharge Pressure Suction Pressure
All pressures are in bar. Suction pressure drops gradually throughout the freeze cycle.
10 7.58-4.48 1.72-.14 2.41-4.14 1.38-2.07
20 11.03-5.86 1.94-.28 3.45-5.87 1.72-3.45
25 13.10-7.24 1.94-.34 3.79-6.55 2.07-4.14
32 15.86-9.31 1.94-.41 4.82-8.27 2.76-4.82
43 21.37-11.72 2.34-.48 5.17-11.72 3.45-7.93
