–154–
EC80 SELF-CONTAINED AIR-COOLED — LARGE CUBE (Continued)
24 Hour Ice Production.
Air Temp. Entering
Condenser °C
Water Temperature °C
10 15 20 25 30 35 40
10 93.3
15 85.1 82.4
20 78.4 75.7 73.0 70.3 66.9
25 71.8 66.7 66.3 63.6 60.9
30 65.1 62.4 59.6 56.9 54.2 51.5 48.8
35 53.0 50.2 47.5 44.8 42.1
40 40.8 38.1 35.4
45 34.2 31.4 28.7
Based on average ice weight of 1.49 - 1.58 kg per cycle. Individual cube weight 32 grams ±1.
Number of individual cubes per cycle: 48
