–155–
EC80 SELF-CONTAINED AIR-COOLED — LARGE CUBE (Continued)
Operating Pressures
Air Temp. Entering
Condenser °C
Freeze Cycle Harvest Cycle
Discharge Pressure Suction Pressure Discharge Pressure Suction Pressure
All pressures are in bar. Suction pressure drops gradually throughout the freeze cycle.
10 13.79-9.65 3.45-1.59 6.89-8.27 4.48-5.17
20 13.79-17.24 4.48-1.72 9.65-11.38 5.86-6.89
25 18.62-14.48 4.48-1.79 11.03-12.41 6.89-8.27
32 21.37-17.24 4.69-2.07 12.41-15.17 7.58-10.00
43 26.20-22.75 5.17-2.48 13.79-17.24 9.30-12.07
