Manitowoc National Crane 800D User Manual

National Crane Published 5-27-2018 Control # 039-06 10-9
800D CRANE INSTALLATION
COUNTERWEIGHTING METHODS FOR STABILITY
AROUND THE REAR 180°
CENTER OF BED CWT
HEAVY BUMPER
HEAVY BUMPER
1100 LB (498 kg)
800 LB (362 kg)
500 LB (227 kg)
WEIGHTED AREA
TRUCK BED BOTTOM VIEW
BED COUNTERWEIGHTING
FOR 1150 LB (520 kg)
BED COUNTERWEIGHTING
FOR 2000 LB (910 kg)
BED COUNTERWEIGHTING
FOR 3000 LB (1360 kg)
86 in
(2184 mm)
86 in
(2184 mm)
86 in
(2184 mm)
40 in
(1016 mm)
70 in
(1778 mm)
105 in
(2667 mm)
4 in
(102 mm)
20 in
(508 mm)
CG
52.5 in
(1334 mm)
CG
NOTE: SHADED AREAS INDICATE CONCRETE
35 in
(889 mm)
CG
4 in
(102 mm)
4 in
(102 mm)
9452
Fo
r
Reference
Only
