Marantz AV7701 - Page 133

133
1.PREFMUTE 17.NC 16.H/PL 15.H/PGND 14.H/PR 13.H/P_RLY 12.FRONT_RLY 11.C/S_RLY 10.RELAY_SB 9.RLY_AMPSB 8.FH_RLY 7.FW_RLY 6.MUTE_3.3V 5.P_PREFHMUTE 4.PREZ3_MUTE 3.PREZ2_MUTE 2.PRESBMUTE
15.ETHER_CVBS 14.VGND 13.V.AUX_V_IN 12.VGND 11.DEC_CVBS_IN 10.VGND 9.DEC_Y_IN 8.VGND 7.DEC_PB_IN 6.VGND 5.DEC_PR_IN 4.VGND 3.AVSCL 2.VGND 1.AVSDA
11.VGND 10.ENC_CVBS_OUT 9.VGND 8.ENC_Y_OUT 7.VGND 6.ENC_PB_OUT 5.VGND 4.ENC_PR_OUT 3.VGND 2.NC 1.VIDEO+5V
11.MVOLCLK 9.ZVOLSTB 7.ZVOLCLK 5.DM860R 3,DM860L 10.MVOLDATA 8.ZVOLDATA 6.DAGND 4.DAGND 2.DAGND 1.DAGND 27.MICGND 26.MIC 25.AGND 23.AGND 24.VAUXR 22.VAUXL 21.DACARTGND 20.DACARTGND 19.DASBR 17.DASBL 18.DAGND 16.DAGND 15.DASR 13.DASL 14.DAGND 12.DAGND 11.DASW 9.DAC 10.DAGND 8.DAGND 7.DAFR 5.DAFL 6.DAGND 4.DAGND 3.ADINR 2.DAGND 1.ADINL
17.PREFMUTE 16.PRESBMUTE 15.PREZ2_MUTE 14.PREZ3_MUTE 13.P_PREFHMUTE 12.MUTE_3.3V 11.FW_RLY 10.FH_RLY 8.RELAY_SB 7.C/S_RLY 6.FRONT_RLY 5.H/P_RLY 4.H/PR 3.H/PGND 2.H/PL 1.NC 9.RLY_AMPSB
27.MICGND 26.MIC 25.AGND 23.AGND 24.VAUXR 22.VAUXL 21.DACARTGND 20.DACARTGND 19.DASBR 17.DASBL 18.DAGND 16.DAGND 15.DASR 13.DASL 14.DAGND 12.DAGND 11.DASW 9.DAC 10.DAGND 8.DAGND 7.DAFR 5.DAFL 6.DAGND 4.DAGND 3.ADINR 2.DAGND 1.ADINL
11.VGND 10.ENC_CVBS_OUT 9.VGND 8.ENC_Y_OUT 7.VGND 6.ENC_PB_OUT 5.VGND 4.ENC_PR_OUT 3.VGND 2.NC 1.VIDEO+5V
11.MVOLCLK 9.ZVOLSTB 7.ZVOLCLK 5.DM860R 3,DM860L 10.MVOLDATA 8.ZVOLDATA 6.DAGND 4.DAGND 2.DAGND 1.DAGND 15.ETHER_CVBS 14.VGND 13.V.AUX_V_IN 12.VGND 11.DEC_CVBS_IN 10.VGND 9.DEC_Y_IN 8.VGND 7.DEC_PB_IN 6.VGND 5.DEC_PR_IN 4.VGND 3.AVSCL 2.VGND 1.AVSDA
FRONT CNT
(FOIL SIDE)
181716151413121110987654321
M
L
K
J
I
H
G
F
E
D
C
B
A
鉛フリー半田
半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。
Lead-free Solder
When soldering, use the Lead-free Solder (Sn-Ag-Cu).
