Marantz AV7701 - Front Cnt

132
RPADJ2
ADJ1ICTIC
JW902
17.NC 16.H/PL 15.H/PGND 14.H/PR 13.H/P_RLY 12.FRONT_RLY 11.C/S_RLY 10.RELAY_SB 9.RLY_AMPSB 8.FH_RLY 7.FW_RLY 6.MUTE_3.3V 5.P_PREFHMUTE 4.PREZ3_MUTE 3.PREZ2_MUTE 2.PRESBMUTE 1.PREFMUTE
15.ETHER_CVBS 14.VGND 13.V.AUX_V_IN 12.VGND 11.DEC_CVBS_IN 10.VGND 9.DEC_Y_IN 8.VGND 7.DEC_PB_IN 6.VGND 5.DEC_PR_IN 4.VGND 3.AVSCL 2.VGND 1.AVSDA
11.VGND 10.ENC_CVBS_OUT 9.VGND 8.ENC_Y_OUT 7.VGND 6.ENC_PB_OUT 5.VGND 4.ENC_PR_OUT 3.VGND 2.NC 1.VIDEO+5V
11.MVOLCLK 9.ZVOLSTB 7.ZVOLCLK 5.DM860R 3,DM860L 10.MVOLDATA 8.ZVOLDATA 6.DAGND 4.DAGND 2.DAGND 1.DAGND 27.MICGND 26.MIC 25.AGND 23.AGND 24.VAUXR 22.VAUXL 21.DACARTGND 20.DACARTGND 19.DASBR 17.DASBL 18.DAGND 16.DAGND 15.DASR 13.DASL 14.DAGND 12.DAGND 11.DASW 9.DAC 10.DAGND 8.DAGND 7.DAFR 5.DAFL 6.DAGND 4.DAGND 3.ADINR 2.DAGND 1.ADINL
BAR CODE LABEL
DIP OUT
CNT_CUP12444Z_A_1(MP)
1.NC 2.H/PL 3.H/PGND 4.H/PR 5.H/P_RLY 6.FRONT_RLY 7.C/S_RLY 8.RELAY_SB 9.RLY_AMPSB 10.FH_RLY 11.FW_RLY 12.MUTE_3.3V 13.P_PREFHMUTE 14.PREZ3_MUTE 15.PREZ2_MUTE 16.PRESBMUTE 17.PREFMUTE
11.MVOLCLK 9.ZVOLSTB 7.ZVOLCLK 5.DM860R 3,DM860L 10.MVOLDATA 8.ZVOLDATA 6.DAGND 4.DAGND 2.DAGND 1.DAGND
27.MICGND 26.MIC 25.AGND 23.AGND 24.VAUXR 22.VAUXL 21.DACARTGND 20.DACARTGND 19.DASBR 17.DASBL 18.DAGND 16.DAGND 15.DASR 13.DASL 14.DAGND 12.DAGND 11.DASW 9.DAC 10.DAGND 8.DAGND 7.DAFR 5.DAFL 6.DAGND 4.DAGND 3.ADINR 2.DAGND 1.ADINL
15.ETHER_CVBS 14.VGND 13.V.AUX_V_IN 12.VGND 11.DEC_CVBS_IN 10.VGND 9.DEC_Y_IN 8.VGND 7.DEC_PB_IN 6.VGND 5.DEC_PR_IN 4.VGND 3.AVSCL 2.VGND 1.AVSDA
11.VGND 10.ENC_CVBS_OUT 9.VGND 8.ENC_Y_OUT 7.VGND 6.ENC_PB_OUT 5.VGND 4.ENC_PR_OUT 3.VGND 2.NC 1.VIDEO+5V
CN43A
CN51A
CN21A
CN24A
CN54A
CN29A
CN42A
CN26A CN25A
CN63B
J9603
FRONT CNT
(COMPONENT SIDE)
181716151413121110987654321
M
L
K
J
I
H
G
F
E
D
C
B
A
鉛フリー半田
半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。
Lead-free Solder
When soldering, use the Lead-free Solder (Sn-Ag-Cu).
