FUSE PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
D9311,9312 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D9315 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D9318,9319 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D9322 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D9325 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D9327 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D9330 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
D9332 00D9630328409 DIODE , RECTIFIERS CVD1N4007ST 1
CAPACITORS GROUP
C9317-9319 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C9321-9323 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
RESISTORS GROUP
R7801 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT
R7802 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT
R7809,7810 nsp RES, M-OXIDE FILM(2W/470ohm) CRG2SANJ471RT
R7811 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT
R7812 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT
R7821 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT
R7822 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT
R7831 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT
R7832 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT
R7841 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT
R7842 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT
R7851 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT
R7852 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT
R7861 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT
R7862 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT
R7921-7926 nsp RES, M-OXIDE FILM(1W/2.2Kohm) CRG1SANJ222RT
R7927 NSP RES, CARBON(1/4W,10Kohm,J) CRD25TJ103T
R7934 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R7935-7940 00MGD05330160 RES , CARBON CRD20TJ330T
OTHERS PARTS GROUP
BK931 nsp PCB BRACKET CMD1A629 1
BN932A,933 nsp PINSOCKET(11P,1.25mm,ANGLE,B-TO-B) CJP11HJ282Z 1
CN940 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/5PIN CJP05GI289ZY 1
CN941 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/3PIN CJP03GI289ZY 1
z
F7000,7001 963652010500S FUSE(S506Series,250V,1.6A) CBA2C1600TLEC 1
z
F9001 963652010510S FUSE(S506Series,250V,2A) U CBA2C2000TLEC 1
z
F9001 963652010500S FUSE(S506Series,250V,1.6A) N/K CBA2C1600TLEC 1
z
F9002 652010024008S FUSE(218Series, 250V/1.6A) U KBA2C1600TLEY 1
z
F9002 943652001740S FUSE N/K KBA2C1000TLEY 1
z
F9301 nsp HOLDER , FUSE KJCFC5S 2
z
F9301 963652010500S FUSE(S506Series,250V,1.6A) CBA2C1600TLEC 1
z
F9302 nsp HOLDER , FUSE KJCFC5S 2
